Key Features:



• Centurion Touchscreen Controller:
  • Intuitive and Comprehensive: Easy-to-understand interface with detailed safety information and cabinet alarms.
  • 3D BSC Diagram: Clearly defined alarm types with instructions for proper intervention.
  • Quickstart Mode: Fast and efficient operation.
  • User-Friendly Design: Centered and angled down for easy reach and viewing.

• Dimmable LED Lighting:
  • Adjustable Brightness: Optimal light intensity of 1200 lux.
  • Energy Efficient: Saves energy while providing ideal work comfort.

• Ergonomic Features:
  • 8” Sash Opening: Frameless, shatterproof, UV-absorbing tempered glass.
  • Tray Support Beams and Holder: Reduced vibration and easy drain pan cleaning.

• Advanced Connectivity:
  • USB Port: Access cabinet data log.
  • Remote Modbus: Secure remote access from external devices.

• Superior Construction:
  • S-Series Stainless Steel: Side walls with side capture zones and negative pressure for optimal containment.
  • Single-Piece Work Tray: Spill-retaining and easy to clean.

• Green Product:
  • Energy-Efficient DC ECM: Up to 70% energy savings vs AC motor.
  • Low Energy Consumption: 184 watts (4 ft unit) with standby mode for reduced power use.

• ULPA Filter:
  • 10x Filtration Efficiency: Compared to HEPA filters.
  • ISO Class 3 Work Zone: Versus industry-standard ISO Class 5.
  • Long Filter Life: Same 10 years filter life and replacement cost as HEPA filters.

• Isocide™ Antimicrobial Powder Coating:
  • Eliminates Surface Bacteria: 99.9% within 24 hours of exposure.

Models:



• 110-130 VAC, 50/60 Hz
  • AC2-3S9-NS G4 8”: 3ft/0.9m, 8-inch opening
  • AC2-4S9-NS G4 8”: 4ft/1.2m, 8-inch opening
  • AC2-5S9-NS G4 8”: 5ft/1.5m, 8-inch opening
  • AC2-6S9-NS G4 8”: 6ft/1.8m, 8-inch opening

Accessories:



• UV Lamps: For different cabinet sizes.
• GFCI and Electrical Outlets: For various models.
• IV Bars: Different lengths available.
• Support Stands: Telescoping with leveling feet and castors.
• Service Fixtures: For gas, vacuum, air, nitrogen, and water.
• Exhaust Collars and Accessories: Including anti-blowback valves and volumetric exhaust dampers.
• VHP IN/OUT Ports: With or without exhaust collars.
• Arm and Foot Rests: For added comfort.

Brochures and References:



• Airstream® NS G4 Brochure
• Airstream® NS G4 Spanish Brochure
• Airstream® NS G4 US Brochure
• BSC Maintenance Tips and Procedures
• Heightened Security and Excellence in Lab Safety

Certificates:



• CE Declaration – AC2-NS G4
• UKCA-AC2-NS G4
• NSF Listing
